1080p 720p HD Thermal imaging FLIR cameras

XGA 1024×768 Scientific/security analysis FLIR HD Thermal Infrared Imaging cameras

Scientific Grade IRXP Series thermal imaging HD cameras radiometric security/surveillance flir

The IRXP series of XGA 1024×768 resolution HD LWIR thermal IR imaging therma camera is a low cost, highly customizable and sensitive scientific grade thermal infrared FLIR imaging camera with full analysis, radiometric temperature measurement. These XGA 1024×768 HD resolution LWIR units can be used for deep thermal analysis imaging from close up ultra small microscope optics to long range imaging.

Pcb xga thermal imaging

The xga 1024 x 768 HD Z1000 camera is radiometric unique exotic dual thermal imaging flir camera which can be used for affordable low cost scientific xga thermal analysis imaging applications as well as security and surveillance thermal imaging applications. This xga HD 1024×768 Ir camera comes available with a wide variety of lenses for ultra close up microscope imaging all the way to long range security detection applications.

IRXP 5001 used radiometric infrared camera rear connections

IRXP 5001 used radiometric infrared camera rear connections

XGA flir thermal camera

1080p 720p HD Thermal imaging FLIR cameras

1080p 720p HD Thermal imaging FLIR cameras

The Units come in 3 resolution variants

Z300 has 384×228 resolution
Z600 has VGA 640×512 resolution
Z1000 has XGA 1024×768 HD resolution

SHORT MEDIUM AND LONG RANGE THERMAL LENSES ARE AVAILABLE

ACS-55 Multi Sensor Military Sight

ACS-55 Multi Sensor Military Sight

PTZ FLIR

M9_PTZ_MWIR_COOLED_LONG_RANGE_THERMAL_FLIR_IMAGING_CAMERA

Applications

– Security and Surveillance
– Unmanned Aerial Vehicles(UAVs), drones, Uas, and robotics applications
– Machine Vision / thermography / pcb mapping
– Medical Imaging
– Fire Detection
– Quality Control
– R&D / Scientific / PCB analysis imaging

Features

* 384 x 288/ 640 x 480 VGA  / 1024 x 768 XGA HD ir Resolution
* Various FOV lenses Available
* Rapid Video Frame Rate 60Hz(NTSC)/50Hz(PAL)
* High resolution / high sensitivity imaging
* Flexibility in Customizing
* Low Price HD 720p xga 1024×768 thermal flir camera core engine used in a variety of custom Oem/odm imaging applications

Model Name Z300
Resolution 384×288 / 640×480 / 1024×768
Pixel Pitch 17 or 12 µm
Detector Type LWIR, Uncooled a-Si Microbolometer
thermal Sensitivity(NETD) <50 mk
Spectral Range 8 – 14 µm
Radiometric Type X
Measurement Range X
Accuracy X
Color Variation(Palette) 10 colors(Grey,Iron, Rain_v1,2,3/Half_Grey/Yellow/MidGrey/Fire/BlueRed)
Image Setting AGC, Level&Span, NUC, Mirror, Flip, Invert, Image Filter on Screen Menu
Zoom 2x & 4x Digital Zoom
focus Manual, Motorized, Athermalized
Alarm X
Function Hot/Cold tracker, Center indicator
System TV Mode NTSC/PAL Compatible
Temp. Output Interface X
Protocol SPI own proprietary
OSD Pelco-D(RS485)
Video Output Interface Standard BNC Connector(Composite), HDMI Supported
Frame Rate 60Hz
Start-up <2 Seconds
Modularized Type O
Modularized type doesn`t support OSD, and protocol is SPI own proprietary protocol by RS232
PC Software X
Optional Outdoor Housing with Germanium Window(Encapsulation : IP 66), Motorized, Athermalized and Optic Zoom lens, Module Type available
Dimensions(L.W.H) 132.08 x 77.6 x 67.6 mm
Input Voltage 110 to 220V AC(DC 12V)
Operating Temperature -15°C ~ 50°C
Store Temperature -40°C ~ 70°C
Power Consumption 12 VDC : 5W
Weight Approx. 500g(without lens) *up to 1.47Kg including 100mm lens
Model Name Z600
Resolution 640×480
Pixel Pitch 17µm
Detector Type LWIR, Uncooled a-Si Microbolometer
thermal Sensitivity(NETD) <50 mk
Spectral Range 8 – 14 µm
Radiometric Type X
Measurement Range X
Accuracy X
Color Variation(Palette) 10 colors(Grey,Iron, Rain_v1,2,3/Half_Grey/Yellow/MidGrey/Fire/BlueRed)
Image Setting AGC, Level&Span, NUC, Mirror, Flip, Invert, Image Filter on Screen Menu
Zoom 2x & 4x Digital Zoom
focus Manual, Motorized, Athermalized
Alarm X
Function Hot/Cold tracker, Center indicator
System TV Mode NTSC/PAL Compatible
Temp. Output Interface X
Protocol SPI own proprietary
OSD Pelco-D(RS485)
Video Output Interface Standard BNC Connector(Composite), HDMI Supported
Frame Rate 50Hz
Start-up <2 Seconds
Modularized Type O
Modularized type doesn`t support OSD, and protocol is SPI own proprietary protocol by RS232
PC Software X
Optional Outdoor Housing with Germanium Window(Encapsulation : IP 66), Motorized, Athermalized and Optic Zoom lens, Module Type available
Dimensions(L.W.H) 132.08 x 77.6 x 67.6 mm
Input Voltage 110 to 220V AC(DC 12V)
Operating Temperature -15°C ~ 50°C
Store Temperature -40°C ~ 70°C
Power Consumption 12 VDC : 5W
Weight Z600 Camera: Approx. 500g(without lens)
Model Name Z1000
Resolution 1024×768 xga 720p HD fpa detector
Pixel Pitch 17µm
Detector Type LWIR, Uncooled a-Si Microbolometer sensor
thermal Sensitivity(NETD) <50 mk
Spectral Range 8 – 14 µm
Radiometric Type X
Measurement Range X
Accuracy X
Color Variation(Palette) 10 colors(Grey,Iron, Rain_v1,2,3/Half_Grey/Yellow/MidGrey/Fire/BlueRed)
Image Setting AGC, Level&Span, NUC, Mirror, Flip, Invert, Image Filter on Screen Menu
Zoom 2x & 4x Digital Zoom
focus Manual, Motorized, Athermalized
Alarm X
Function Hot/Cold tracker, Center indicator
System TV Mode NTSC/PAL Compatible
Temp. Output Interface X
Protocol SPI own proprietary
OSD Pelco-D(RS485)
Video Output Interface Standard BNC Connector(Composite), HDMI Supported
Frame Rate 50Hz
Start-up <2 Seconds
Modularized Type O
Modularized type doesn`t support OSD, and protocol is SPI own proprietary protocol by RS232
PC Software X
Optional Outdoor Housing with Germanium Window(Encapsulation : IP 66), Motorized, Athermalized and Optic Zoom lens, Module Type available
Dimensions(L.W.H) 132.08 x 77.6 x 67.6 mm
Input Voltage 110 to 220V AC(DC 12V)
Operating Temperature -15°C ~ 50°C
Store Temperature -40°C ~ 70°C
Power Consumption 12 VDC : 5W
Weight Approx. 500g(without lens) *up to 1.47Kg including 100mm lens



HD LWIR Lens options;

35.0mm f1.0
manual

35.0mm f1.0
motorized

50.0mm f1.0
manual

50.0mm f1.0
motorized

75.0mm f1.0
manual

75.0mm f1.0
motorized

100.0mm f1.0
manual

100.0mm f1.0
motorized

130mm f1.0
motorized

130mm f1.2
motorized

150mm f1.0
motorized

150mm f1.2
motorized

200mm f1.0
motorized

200mm f1.3
motorized

250mm f1.0
motorized

250mm f1.3
motorized

Lenses available from Ultra close focus Microscope thermal lenses, all the way up to 250 mm Narrow Long Range lenses

Contact mike@x20.org for additional information or call 702-499-9551
